MF800C
IMSA’s simplest deep drilling machine for blocks and plates, and for off-center deep holes in cylindrical parts. Drilling depth max. 800 mm. Table load: 2000 kg on optional rotary table; 4000 kg on standard fixed table.
IMSA manufactured more than 600 deep drilling machines so far; among these, 450 are operating in the tool and mold making industry, in gun drilling job shops and moldmakers for plastic injection moulding industry and glass industry. Read a technical introduction about this holemaking technology in our article “The Deep Drilling Process”.
The never-ending quest to research/develop new technology solutions for our automatic gun drilling machines has always played a fundamental role for our team. Many of the recent innovations applied to deep drilling machines for moldmakers were developed by IMSA (Learn more in this article published in 2019 for IMSA 30th Anniversary).
FOR MOLDS UP TO 6 TONS APPROX
IMSA’s simplest deep drilling machine for blocks and plates, and for off-center deep holes in cylindrical parts. Drilling depth max. 800 mm. Table load: 2000 kg on optional rotary table; 4000 kg on standard fixed table.
IMSA simple 3-4 axes solution for blocks, mold inserts and plates.
The IMSA deep hole drilling machine MF1200D can also be used to drill centered and off-center deep holes in cylindrical parts.
Drilling depth in single operation max. 1200 mm. Table load 4000 kg.
Gun drilling and milling machine molds and mechanical parts up to 2 or 4 tonnes, depending on the chosen table.
Gun drilling and milling machine for small to middle-size molds. Straight (3-axis) and single-angle (4-axis) drillings: this machine version is equipped with a rotary table.
Gun drilling and milling machine for small to middle-size molds with complex waterlines. Straight (3-axis), single-angle (4-axis) and compound-angle (5-axis) drillings: this machine version is equipped with a rotary tilting table.
Gundrilling and milling machine for small to middle-size molds with complex waterlines. Straight, single-angle and compound-angle drilling: this machine version is equipped with a rotary tilting table.
FOR MOLDS UP TO 12 TONS APPROX
“GUNDRILLING AND MILLING IN SINERGY”: EVO-Series Gun Drilling and Milling Center for molds that require multiple-axis waterlines.
“TOP AUTOMATION IN GUN DRILLING”: EVO-Series Gun Drilling and Milling center, equipped with IMSA’s 4-station Gun Drill Changer
TABLE LOAD FROM 20 UP TO 45 TONS
The milling and gun drilling center IMSA MF1600S2 is designed for manufacturers of tool and dies up to 30 tons in the mold making industry. T-shape machine concept: translating table and transversal movable column.
“GUNDRILLING AND MILLING IN SINERGY”: EVO-Series Gundrilling and Milling Center for molds that require multiple-axis waterlines. Vertical Gantry structure. The Gun Drill Center MF1750EVO is suitable for large molds up to 30 / 40 / 45 tonnes, depending on the selected table. A workpiece of diameter 4,300mm max can rotate inside the machine structure.
